| LENGTH | 30" | 762 mm |
| WIDTH | 21" | 533.4 mm |
Product Capacity: 21″ x 30″ x 4.25″
Maximum Standard Forming Pressure Capacity: 100 PSI
Material Capacity: Up To 32″ Width of Standard Packaging Sheet and Films, 0.0075″ to 0.030″ in Thickness
Cutting Capacity: 0.0075″ to 0.030″ in Thickness, Up To 480 Linear Inches of Knife
Heating Control: Max 200 Degrees C
Air Requirements: Approx. 70 CFM of Free Air at 18 Cycles Per Minute
Electrical Supply: 480 Volts / 3 Phase / 60 Amps Per Leg
Water Consumption: Max 75 Gal/Hr
Productivity: ~700 to 1500 Cycles Per Hour
Dimensions: 95″ L x 44.5″ W x 85″ H
Weight: ~6,000 Lbs
